FET, MOSFET
| Фото | Парт. № производителя | Наличие | Количество | Техническая документация | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип полевого транзистора | Технология | Напряжение сток-исток (Vdss) | Ток - Непрерывный сток (Id) @ 25°C | Напряжение управления (Макс. Rds On, Мин. Rds On) | Rds On (Макс.) @ Id, Vgs | Vgs(th) (Макс.) @ Id | Заряд затвора (Qg) (Макс.) @ Vgs | Vgs (макс.) | Входная емкость (Ciss) (Макс.) @ Vds | Характеристика FET | Рассеиваемая мощность (макс.) | Рабочая температура | Марка | Квалификация | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
STF25N80K5MOSFET N-CH 800V 19.5A TO220FP |
315 |
|
Техническая документация |
SuperMESH5™ | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 19.5A (Tc) | 10V | 260mOhm @ 19.5A, 10V | 5V @ 100µA | 40 nC @ 10 V | ±30V | 1600 pF @ 100 V | - | 40W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220FP |
|
STO36N60M6MOSFET N-CH 600V 30A TOLL |
446 |
|
Техническая документация |
MDmesh™ M6 | 8-PowerSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 30A (Tc) | 10V | 99mOhm @ 15A, 10V | 4.75V @ 250µA | 44.3 nC @ 10 V | ±25V | 1960 pF @ 100 V | - | 230W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TOLL (HV) |
|
FDBL9406-F085T6MOSFET N-CH 40V 45A/240A 8HPSOF |
1,889 |
|
Техническая документация |
- | 8-PowerSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 45A (Ta), 240A (Tc) | - | 1.21mOhm @ 50A, 10V | 3.5V @ 190µA | 75 nC @ 10 V | +20V, -16V | 4960 pF @ 25 V | - | 4.3W (Ta), 136.4W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 8-HPSOF |
|
STH180N10F3-2MOSFET N-CH 100V 180A H2PAK-2 |
614 |
|
Техническая документация |
STripFET™ III | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 180A (Tc) | 10V | 4.5mOhm @ 60A, 10V | 4V @ 250µA | 114.6 nC @ 10 V | ±20V | 6665 pF @ 25 V | - | 315W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | H2PAK-2 |
|
RBA250N04AHPF-4UA01#GB0POWER TRS2 AUTOMOTIVE MOS MP-25L |
2,447 |
|
Техническая документация |
- | TO-263-7, D2PAK (6 Leads + Tab), TO-263CB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 250A (Tc) | 10V | 0.85mOhm @ 125A, 10V | 4V @ 250µA | 368 nC @ 10 V | ±20V | 19350 pF @ 25 V | - | 1.8W (Ta), 348W (Tc) | 175°C | Automotive | AEC-Q101 | Surface Mount | TO-263-7 |
|
STW37N60DM2AGMOSFET N-CH 600V 28A TO247 |
600 |
|
Техническая документация |
MDmesh™ DM2 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 28A (Tc) | 10V | 110mOhm @ 14A, 10V | 5V @ 250µA | 54 nC @ 10 V | ±25V | 2400 pF @ 100 V | - | 210W (Tc) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Through Hole | TO-247-3 |
|
|
STW33N60DM2MOSFET N-CH 600V 24A TO247 |
513 |
|
Техническая документация |
MDmesh™ DM2 | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 24A (Tc) | 10V | 130mOhm @ 12A, 10V | 5V @ 250µA | 43 nC @ 10 V | ±25V | 1870 pF @ 100 V | - | 190W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
IXFH20N50P3MOSFET N-CH 500V 20A TO247AD |
303 |
|
Техническая документация |
HiPerFET™, Polar3™ | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 20A (Tc) | 10V | 300mOhm @ 10A, 10V | 5V @ 1.5mA | 36 nC @ 10 V | ±30V | 1800 pF @ 25 V | - | 380W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247AD (IXFH) |
|
STB33N60DM6MOSFET N-CH 600V 25A D2PAK |
254 |
|
Техническая документация |
MDmesh™ M6 | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Tc) | 10V | 128mOhm @ 12.5A, 10V | 4.75V @ 250µA | 35 nC @ 10 V | ±25V | 1500 pF @ 100 V | - | 190W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-263 (D2PAK) |
|
R6024VNX3C16600V 24A TO-220AB, PRESTOMOS WIT |
1,055 |
|
Техническая документация |
- | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 24A (Tc) | 10V, 15V | 153mOhm @ 6A, 15V | 6.5V @ 700µA | 38 nC @ 10 V | ±30V | 1800 pF @ 100 V | - | 245W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
IPP60R070CFD7XKSA1MOSFET N-CH 650V 31A TO220-3 |
700 |
|
Техническая документация |
CoolMOS™ CFD7 | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 31A (Tc) | 10V | 70mOhm @ 15.1A, 10V | 4.5V @ 760µA | 67 nC @ 10 V | ±20V | 2721 pF @ 400 V | - | 156W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO220-3 |
|
NTHL095N65S3HFMOSFET N-CH 650V 36A TO247-3 |
316 |
|
Техническая документация |
FRFET®, SuperFET® III | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 36A (Tc) | 10V | 95mOhm @ 18A, 10V | 5V @ 860µA | 66 nC @ 10 V | ±30V | 2930 pF @ 400 V | - | 272W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-247-3 |
|
STB20NM50T4MOSFET N-CH 550V 20A D2PAK |
698 |
|
Техническая документация |
MDmesh™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 550 V | 20A (Tc) | 10V | 250mOhm @ 10A, 10V | 5V @ 250µA | 56 nC @ 10 V | ±30V | 1480 pF @ 25 V | - | 192W (Tc) | -65°C ~ 150°C (TJ) | - | - | Surface Mount | D2PAK |
|
SIHK105N60E-T1-GE3E SERIES POWER MOSFET WITH FAST |
2,050 |
|
Техническая документация |
EF | 8-PowerBSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 24A (Tc) | 10V | 105mOhm @ 10A, 10V | 5V @ 250µA | 51 nC @ 10 V | ±30V | 2301 pF @ 100 V | - | 142W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK®10 x 12 |
|
FDB0190N807LMOSFET N-CH 80V 270A TO263-7 |
663 |
|
Техническая документация |
PowerTrench® | TO-263-7, D2PAK (6 Leads + Tab) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 270A (Tc) | 8V, 10V | 1.7mOhm @ 34A, 10V | 4V @ 250µA | 249 nC @ 10 V | ±20V | 19110 pF @ 40 V | - | 3.8W (Ta), 250W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | TO-263-7 |
|
IXTQ76N25TMOSFET N-CH 250V 76A TO3P |
300 |
|
Техническая документация |
Trench | TO-3P-3, SC-65-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 250 V | 76A (Tc) | 10V | 39mOhm @ 500mA, 10V | 5V @ 1mA | 92 nC @ 10 V | ±30V | 4500 pF @ 25 V | - | 460W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-3P |
|
IPW65R115CFD7AXKSA1MOSFET N-CH 650V 21A TO247-3-41 |
240 |
|
Техническая документация |
CoolMOS™ CFD7A | TO-247-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 21A (Tc) | 10V | 115mOhm @ 9.7A, 10V | 4.5V @ 490µA | 41 nC @ 10 V | ±20V | 1950 pF @ 400 V | - | 114W (Tc) | -40°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Through Hole | PG-TO247-3-41 |
|
|
IXTP230N075T2MOSFET N-CH 75V 230A TO220AB |
344 |
|
Техническая документация |
TrenchT2™ | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 230A (Tc) | 10V | 4.2mOhm @ 50A, 10V | 4V @ 250µA | 178 nC @ 10 V | ±20V | 10500 pF @ 25 V | - | 480W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | TO-220-3 |
|
|
IXTP120P065TMOSFET P-CH 65V 120A TO220AB |
173 |
|
Техническая документация |
TrenchP™ | TO-220-3 | Tube | Active | P-Channel | MOSFET (Metal Oxide) | 65 V | 120A (Tc) | 10V | 10mOhm @ 500mA, 10V | 4V @ 250µA | 185 nC @ 10 V | ±15V | 13200 pF @ 25 V | - | 298W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220-3 |
|
SIHK105N60EF-T1GE3E SERIES POWER MOSFET POWERPAK 1 |
1,990 |
|
Техническая документация |
EF | 8-PowerBSFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 24A (Tc) | 10V | 105mOhm @ 10A, 10V | 5V @ 250µA | 51 nC @ 10 V | ±30V | 2301 pF @ 100 V | - | 142W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK®10 x 12 |
