DC-DC Преобразователи
| Фото | Парт. № производителя | Наличие | Количество | Техническая документация | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - вход (мин.) | Напряжение - вход (макс.) | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Ток - выход (макс.) | Мощность (Вт) | Напряжение - Изоляция | Применение | Особенности | Рабочая температура | Эффективность | Марка | Квалификация | Тип крепления | Размер/измерение | Устройство поставщика Упаковка | Функции управления | Сертифицирующее агентство | Стандартный номер |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MPU01-12S3P3DC DC CONVERTER 3.3V 1W |
3,167 |
|
Техническая документация |
MPU01 (1W) | 9-SIP Module, 4 Leads | Tube | Active | Isolated Module | 1 | 9.6V | 14.4V | 3.3V | - | - | - | 303mA | 1 W | 5 kV | ITE (Commercial), Medical | Adjustable Output | -40°C ~ 105°C (With Derating) | 80% | - | - | Through Hole | 0.77" L x 0.39" W x 0.49" H (19.6mm x 9.9mm x 12.5mm) | - | - | CB, CE, cURus | 60601-1; 62368-1 |
|
RCD20-110S3P3WDC DC CONVERTER 3.3V 18W |
3,773 |
|
Техническая документация |
RCD20W (20W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 36V | 160V | 3.3V | - | - | - | 5.5A | 18 W | 3 kV | ITE (Commercial), Railway | Adjustable Output, Remote On/Off | -40°C ~ 105°C (With Derating) | 88% | - | - | Through Hole | 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm) | - | Enable, Active Low | CB, CE, cURus | 62368-1 |
|
EM2130L01QIESIC SOC REG DC CONVERTER QFN |
4,361 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EN5311QI-CDC DC CONVERTER |
1,487 |
|
Техническая документация |
- | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EQC1240QIDC DC CONVERTER |
1,354 |
|
Техническая документация |
- | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EM2130H01QIESIC SOC REG DC CONVERTER QFN |
1,308 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EM2121H01QIIC SOC REG DC CONVERTER QFN |
1,480 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EX3AVDC DC CONVERTER |
2,477 |
|
Техническая документация |
- | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EM2140P01QIESIC SOC REG DC CONVERTER QFN |
2,945 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EM2121L01QIIC SOC REG DC CONVERTER QFN |
2,296 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
ET2760ALIIC POWER SOC QFN |
1,645 |
|
Техническая документация |
- | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
UEI15-033-Q12-CDC DC CONVERTER 3.3V 14.85W |
4,338 |
|
Техническая документация |
UEI15 (15W) | 6-DIP Module | Tray | Active | Isolated Module | 1 | 9V | 36V | 3.3V | - | - | - | 4.5A | 14.85 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Standby Output | -40°C ~ 85°C (With Derating) | 89% | - | - | Through Hole | 1.10" L x 0.96" W x 0.33" H (27.9mm x 24.4mm x 8.4mm) | - | Enable, Active High | cURus, DEMKO | 60950-1 |
|
|
CPT1U48NDC DC CONVERTER 48V 60W |
3,753 |
|
Техническая документация |
CPT (60W) | Sixteenth Brick | Tray | Active | Isolated Module | 1 | 36V | 75V | 48V | - | - | - | 1.25A | 60 W | 2.25 kV | ITE (Commercial) | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 85°C (With Derating) | 90% | - | - | Through Hole | 1.30" L x 0.90" W x 0.37" H (33.0mm x 22.9mm x 9.5mm) | Sixteenth Brick | Enable, Active Low | CSA, TUV, UL | - |
|
|
PQM3-D48-S12-MDC DC CONVERTER 12V 3W |
4,753 |
|
Техническая документация |
PQM3-M (3W) | 16-SMD Module, 6 Leads | Tube | Obsolete | Isolated Module | 1 | 36V | 75V | 12V | - | - | - | 250mA | 3 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 80% | - | - | Surface Mount | 0.94" L x 0.54" W x 0.31" H (23.9mm x 13.7mm x 8.0mm) | - | - | EN | 55024; 55032 Class A |
|
|
PQM3-D48-S15-MDC DC CONVERTER 15V 3W |
3,506 |
|
Техническая документация |
PQM3-M (3W) | 16-SMD Module, 6 Leads | Tube | Obsolete | Isolated Module | 1 | 36V | 75V | 15V | - | - | - | 200mA | 3 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 80% | - | - | Surface Mount | 0.94" L x 0.54" W x 0.31" H (23.9mm x 13.7mm x 8.0mm) | - | - | EN | 55024; 55032 Class A |
|
|
PQM3-D48-S5-MDC DC CONVERTER 5V 3W |
2,271 |
|
Техническая документация |
PQM3-M (3W) | 16-SMD Module, 6 Leads | Tube | Obsolete | Isolated Module | 1 | 36V | 75V | 5V | - | - | - | 600mA | 3 W | 1.5 kV | ITE (Commercial) | SCP | -40°C ~ 105°C (With Derating) | 77% | - | - | Surface Mount | 0.94" L x 0.54" W x 0.31" H (23.9mm x 13.7mm x 8.0mm) | - | - | EN | 55024; 55032 Class A |
|
|
ZL9122MAIRZIC REGULATOR |
3,837 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
ZL9122MIRZ-TIC REGULATOR |
3,372 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
ZL9122MIRZIC REGULATOR |
4,349 |
|
Техническая документация |
- | - | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
ZL9006MAIRZ-TS2490IC REGULATOR |
2,629 |
|
Техническая документация |
ZL9006M | 32-SMD Module | Tray | Obsolete | Non-Isolated PoL Module, Digital | 1 | 4.5V | 13.2V | 0.54 ~ 3.6V | - | - | - | 6A | - | - | ITE (Commercial) | Adjustable Output, I2C Interface, Load Sharing, PMBus™, Remote On/Off | -40°C ~ 125°C | - | - | - | Surface Mount | 0.68" L x 0.45" W x 0.10" H (17.2mm x 11.5mm x 2.5mm) | 32-HDA Module (17.2x11.45) | Enable, Active High | - | - |
What is a DC-DC converter?
A DC-DC converter is equipment that converts DC into DC.
Kinds of DC-DC converters
Generally, there are four kinds of DC-DC converters. Their names are as follows.
| Kind | Generic name |
|---|---|
| Power supply equipment that reduces the voltage | Buck converter, Step-down converter |
| Power supply equipment that increases the voltage | Boost converter, Step-up converter |
| Power supply equipment that increases and decreases the voltage | Buck-Boost converter |
| Power supply equipment that generates a negative voltage | Negative voltage converter, Inverting converter |
What is POL (Point of Load)?
POL is a DC-DC converter installed in the immediately vicinity of a microprocessor or an LSI (Large-Scale Integrated circuit) such as a DSP, FPGA or ASIC.
POL Trends
In the light of this background, POL is required to have "voltage accuracy," "load fluctuation transient response," "low radiation noise," and "compactness."
Features of MonoBK™ with illustrations
1. Small mounting area
Downsizing by circuit design based on extensive power supply design know-how and mounting the inductor in a 3D structure
2. High power density / good heat dissipation characteristics
Enhanced heat dissipation effect with resin molding and thinner printed circuit board
3. Low noise
Reduced noise with minimization of the current loop using a 3D structure and extensive EMI noise knowledge
Fig. MYMGK1R820ERSR EMI data
4. High reliability
Improved heat shock resistance with resin molding
