Цифровые изоляторы
| Фото | Парт. № производителя | Наличие | Количество | Техническая документация | Серия | Корпус/корпус | Упаковка | Состояние продукта | Технология | Тип | Изолированное питание | Количество каналов | Входы - Сторона 1/Сторона 2 | Тип канала | Напряжение - Изоляция | Устойчивость к синфазным переходным процессам (мин.) | Скорость передачи данных | Задержка распространения tpLH / tpHL (макс.) | Искажение ширины импульса (макс.) | Время нарастания/спада (тип.) | Напряжение - Питание | Марка | Квалификация | Рабочая температура | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ADUM6202ARWZ-RLDGTL ISO 5000VRMS 2CH GP 16SOIC |
2,943 |
|
Техническая документация |
IsoPower®, iCoupler® | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 2 | 0/2 | Unidirectional | 5000Vrms | 25kV/µs | 1Mbps | 100ns, 100ns | 40ns | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 16-SOIC |
|
|
ADUM6200ARWZ-RLDGTL ISO 5000VRMS 2CH GP 16SOIC |
3,586 |
|
Техническая документация |
IsoPower®, iCoupler® | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 2 | 2/0 | Unidirectional | 5000Vrms | 25kV/µs | 1Mbps | 100ns, 100ns | 40ns | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 16-SOIC |
|
ISO721MMDREPG4DGTL ISO 4000VPK 1CH GP 8SOIC |
4,100 |
|
Техническая документация |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Discontinued at Digi-Key | Capacitive Coupling | General Purpose | No | 1 | 1/0 | Unidirectional | 4000Vpk | 25kV/µs | 150Mbps | 16ns, 16ns | 1ns | 1ns, 1ns | 3V ~ 3.6V, 4.5V ~ 5.5V | - | - | -55°C ~ 125°C | Surface Mount | 8-SOIC |
|
IL7614VELinear IC's |
4,745 |
|
Техническая документация |
IL761x | 16-SOIC (0.295", 7.50mm Width) | Bulk | Active | Magnetic Coupling | SPI | Yes | 3 | 2/1 | Unidirectional | 4000Vrms | 30kV/µs | 110Mbps | 18ns, 18ns | 3ns | 2ns, 2ns | 3V ~ 3.6V, 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI8606AC-AS1AUTOMOTIVE 3.75 KV UNI- AND BI-D |
2,426 |
|
Техническая документация |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | I2C | Yes | 4 | 2/2 | Bidirectional, Unidirectional | 3750Vrms | 35kV/µs | 10Mbps | 20ns, 20ns | 12ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI8605AB-AS1AUTOMOTIVE 2.5 KV UNI- AND BI-DI |
4,896 |
|
Техническая документация |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | I2C | Yes | 3 | 2/1 | Bidirectional, Unidirectional | 2500Vrms | 35kV/µs | 10Mbps | 20ns, 20ns | 12ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
MAX14943GWE+TDGTL ISO 5000VRMS RS485 16SOIC |
4,202 |
|
Техническая документация |
- | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | RS485 | No | 3 | 2/1 | Unidirectional | 5000Vrms | 35kV/µs (Typ) | 20Mbps | 68ns, 68ns | - | 15ns, 15ns (Max) | 3V ~ 5.5V, 4.5V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 16-SOIC |
|
|
SI88444EC-ASLINEAR IC |
1,324 |
|
Техническая документация |
Si88x4x | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | Yes | 4 | 0/4 | Unidirectional | 3750Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SOIC |
|
|
SI88443EC-ASLINEAR IC |
1,012 |
|
Техническая документация |
Si88x4x | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | Yes | 4 | 1/3 | Unidirectional | 3750Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SOIC |
|
|
SI88441EC-ASLINEAR IC |
4,090 |
|
Техническая документация |
Si88x4x | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | Yes | 4 | 3/1 | Unidirectional | 3750Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SOIC |
|
|
SI88440EC-ASLINEAR IC |
4,412 |
|
Техническая документация |
Si88x4x | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | Yes | 4 | 4/0 | Unidirectional | 3750Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SOIC |
|
|
SI88442EC-ASLINEAR IC |
4,793 |
|
Техническая документация |
Si88x4x | 20-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | Yes | 4 | 2/2 | Unidirectional | 3750Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SOIC |
|
|
ADUM5200WCRWZ-RLDGTL ISO 2500VRMS 2CH GP 16SOIC |
1,728 |
|
Техническая документация |
- | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 2 | 2/0 | Unidirectional | 2500Vrms | 25kV/µs | 25Mbps | 60ns, 60ns | 6ns | 2.5ns, 2.5ns | 3.3V, 5V | Automotive | - | -40°C ~ 105°C | Surface Mount | 16-SOIC |
|
|
ADUM5202WCRWZ-RLDGTL ISO 2500VRMS 2CH GP 16SOIC |
1,260 |
|
Техническая документация |
- | 16-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 2 | 0/2 | Unidirectional | 2500Vrms | 25kV/µs | 25Mbps | 60ns, 60ns | 6ns | 2.5ns, 2.5ns | 3.3V, 5V | Automotive | - | -40°C ~ 105°C | Surface Mount | 16-SOIC |
|
SI88340ED-ISDGTL ISO 5KV 4CH GEN PURP 24SOIC |
4,118 |
|
Техническая документация |
- | 24-SOIC (0.295", 7.50mm Width) | Tray | Not For New Designs | Capacitive Coupling | General Purpose | No | 4 | 4/0 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 12.6ns, 17.5ns (Typ) | 4.8ns (Typ) | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88341ED-ISDGTL ISO 5KV 4CH GEN PURP 24SOIC |
3,812 |
|
Техническая документация |
- | 24-SOIC (0.295", 7.50mm Width) | Tray | Not For New Designs | Capacitive Coupling | General Purpose | No | 4 | 3/1 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 12.6ns, 17.5ns (Typ) | 4.8ns (Typ) | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88342ED-ISDGTL ISO 5KV 4CH GEN PURP 24SOIC |
1,705 |
|
Техническая документация |
- | 24-SOIC (0.295", 7.50mm Width) | Tray | Active | Capacitive Coupling | General Purpose | No | 4 | 2/2 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 12.6ns, 17.5ns (Typ) | 4.8ns (Typ) | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88343ED-ISDGTL ISO 5KV 4CH GEN PURP 24SOIC |
4,092 |
|
Техническая документация |
- | 24-SOIC (0.295", 7.50mm Width) | Tray | Not For New Designs | Capacitive Coupling | General Purpose | No | 4 | 1/3 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 12.6ns, 17.5ns (Typ) | 4.8ns (Typ) | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
SI88344ED-ISDGTL ISO 5KV 4CH GEN PURP 24SOIC |
2,343 |
|
Техническая документация |
- | 24-SOIC (0.295", 7.50mm Width) | Tray | Not For New Designs | Capacitive Coupling | General Purpose | No | 4 | 0/4 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 12.6ns, 17.5ns (Typ) | 4.8ns (Typ) | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88340BD-ISIC DIGITAL ISOLATOR SOIC |
2,438 |
|
Техническая документация |
- | 24-SOIC (0.295", 7.50mm Width) | Tube | Not For New Designs | Capacitive Coupling | General Purpose | No | 4 | 4/0 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 24-SOIC |
